Barlus 360° Rotating Pan Tilt Camera 30x optical zoom for Underwater Fixed Surveillance
Barlus 360° Rotating Pan Tilt Camera 30x optical zoom for Underwater Fixed Surveillance
Couldn't load pickup availability
For bulk purchases, please contact Tim (sales2@barluscam.com) or click on Chat with us below right to get a discount.🤑
Click below to view parameters👇
Model comparison
Model comparison
Product information
Product information
1 Year Warranty
1 Year Warranty
Please use your Barlus underwater camera with peace of mind. We offer a one year warranty. If there is a quality problem with the camera it can be repaired or returned to you free of charge. Calculated from the date of receipt of the original order.
Shipping
Shipping
Please do note that shipping is insured and takes 6-10 business days worldwide. However, you may receive your items earlier. Tracking Numbers will ALWAYS be sent so you can track them every step of the way! Cool things are worth waiting for!
100% Risk-Free Purchase
100% Risk-Free Purchase
If you bought it and felt that it has some problem, don't worry. Just shoot us a message at contact zhangli@barluscam.com and we will make it right by offering you a replacement or refund. 100% Simple & Risk-Free process.
|
model |
PTZS5Z47141-KX20 |
PTZS8Z47141-KX20 |
|
lens |
4.7-141mm electric zoom lens Wide (H: 60.5, V: 35.1), Tele (H: 2.3, V: 1.3) |
|
|
pixel |
5MP 2592×1944P 50FPS |
8MP 3840*2160P 30fps |
|
fill light |
(Automatic control/manual control) 3 modes ------ 6PCS white light, 10 level brightness. |
|
|
image color settings |
full color |
|
|
support equipment |
Computer,NVR. |
|
|
support agreement |
IPv4/IPv6,802.1x,RTSP,RTMP,ONVIF;HTTP,HTTPS, TCP/IP, UDP, RTP, RTCP, UPNP, RTSP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP,SDK Secondary development |
|
|
texture |
Titanium |
|
|
waterproofing grade |
IP68 (Permanently installed underwater) |
|
|
pipeline pressure test |
Maximum 500Kpa (maximum water depth 50M) |
|
|
cable |
The default length is 20 meters (maximum length is not more than 80 meters),PU material, diameter of 12MM. 60KG tension resistance, aging resistance, friction resistance, seawater corrosion resistance, special underwater wire |
|
|
service environment |
Land/vehicle-borne/shipborne/surface/Underwater (fresh and sea water) |
|
|
PTZ |
Horizontal 360° rotation, vertical 180° |
|
|
PTZ speed |
Horizontal: 160°/S, vertical: 120°/S |
|
|
operating humidity |
0%-100% |
|
|
operating temperature |
-20°~55° |
|
|
Support the voltage |
DC24V 72W |
|
|
Camera size |
⌀175 MM and 400 MM High |
|
|
weight |
13KG（Cable not included） |
|
|
packaging |
1 * camera |
|
|
1 * camera stand fittings |
||
|
1 * U disk (software and manual) |
||
About us
Barlus is a manufacturer that has always been dedicated to creating professional and practical underwater surveillance cameras. Feel free to contact us for any further needs!
Applicable scene
All Products-
Underwater viewing
-
Aquaculture
-
Underwater Engineering Monitoring
