Barlus 360° Rotating Pan Tilt Camera 30x optical zoom for Underwater Fixed Surveillance

Barlus 360° Rotating Pan Tilt Camera 30x optical zoom for Underwater Fixed Surveillance

Regular price $9,912.00 USD
Regular price Sale price $9,912.00 USD
Sale Sold out
Tax included. Shipping calculated at checkout.
Model
Cable
Power supply

For bulk purchases, please contact Tim (sales2@barluscam.com) or click on Chat with us below right to get a discount.🤑

Click below to view parameters👇

Model comparison

Product information

1 Year Warranty

Please use your Barlus underwater camera with peace of mind. We offer a one year warranty. If there is a quality problem with the camera it can be repaired or returned to you free of charge. Calculated from the date of receipt of the original order.

Learn more

Shipping

Please do note that shipping is insured and takes 6-10 business days worldwide. However, you may receive your items earlier. Tracking Numbers will ALWAYS be sent so you can track them every step of the way! Cool things are worth waiting for!

100% Risk-Free Purchase

If you bought it and felt that it has some problem, don't worry. Just shoot us a message at contact zhangli@barluscam.com and we will make it right by offering you a replacement or refund. 100% Simple & Risk-Free process.

model PTZA5Z47141-KX20 PTZA8Z47141-KX20 PTZS5Z47141-KX20 PTZS8Z47141-KX20
lens 4.7-141mm electric zoom lens Wide (H: 60.5, V: 35.1), Tele (H: 2.3, V: 1.3)
pixel 5MP 2592×1944P 50FPS
4MP 2560×1440P 60FPS
3MP 2304×1296P 60FPS
2MP 1920×1080P 60FPS

1/2.8" SONY CMOS sensor ,color 0.001Lux F1.2,black/white 0.0001Lux F1.2
8MP  3840*2160P 30fps
5MP 2592×1944P 30FPS
4MP 2560×1440P 30FPS

1/2.8" SONY CMOS sensor ,color 0.001Lux F1.2,black/white 0.0001Lux F1.2
5MP 2592×1944P 50FPS
4MP 2560×1440P 60FPS
3MP 2304×1296P 60FPS
2MP 1920×1080P 60FPS

1/2.8" SONY CMOS sensor ,color 0.001Lux F1.2,black/white 0.0001Lux F1.2
8MP  3840*2160P 30fps
5MP 2592×1944P 30FPS
4MP 2560×1440P 30FPS

1/2.8" SONY CMOS sensor ,color 0.001Lux F1.2,black/white 0.0001Lux F1.2
fill light (Automatic control/manual control) 3 modes ------ 6PCS white light, 10 level brightness.
image color settings full color
support equipment Computer,NVR.
support agreement IPv4/IPv6,802.1x,RTSP,RTMP,ONVIF;HTTP,HTTPS,  TCP/IP, UDP, RTP, RTCP, UPNP, RTSP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP,SDK Secondary development
texture Aluminium Alloy stainless steel
waterproofing grade IP68 (Permanently installed underwater)
pipeline pressure test Maximum 500Kpa (maximum water depth 50M)
cable The default length is 20 meters (maximum length is not more than 80 meters),PU material, diameter of 12MM. 60KG tension resistance, aging resistance, friction resistance, seawater corrosion resistance, special underwater wire
service environment Land/vehicle-borne/shipborne/surface/Underwater (fresh and sea water)
PTZ Horizontal 360° rotation, vertical 180°
PTZ speed Horizontal: 160°/S, vertical: 120°/S
operating humidity 0%-100%
operating temperature -20°~55°
Support the voltage DC24V 72W
Camera size 175 MM and 400 MM High
weight 10KG 20KG
packaging 1 * camera
1 * camera stand fittings
1 * U disk (software and manual)
View full details

About us

Barlus is a manufacturer that has always been dedicated to creating professional and practical underwater surveillance cameras. Feel free to contact us for any further needs!

  • Underwater viewing

  • Aquaculture

  • Underwater Engineering Monitoring
