Mini 46MM diameter Underwater IP Camera application underwater robot

Mini 46MM diameter Underwater IP Camera application underwater robot

Regular price $530.00 USD
Regular price Sale price $530.00 USD
Sale Sold out
Tax included. Shipping calculated at checkout.
Cable length
Power supply

For bulk purchases, please contact Tim ( or click on Chat with us below right to get a discount.🤑

Click below to view parameters👇

Model comparison

Model UW-46S2-3LDCTX10-led UW-46S2-3LDCTX10 UW-40S2-2DCX10
Lens 2.3MM(H/V:110° /85° Distortionless lens
Focus Length 2M(Support customization)
HD Resolution 2MP1920×1080P25FPS
1/2.8" SONY CMOS sensor ,
color 0.001Lux F1.2,black/white 0.0001Lux F1.2
Illumination 3PCS white led lights,
10 level dimness
(PC/Phone/NVR Setting)
Color Full Color NONE
Camera Housing Material Seawater Grade Stainless steel
Water depth Max3500Kpa   (Max water depth 50M) Maximum 10MPa (Maximum water depth 1000M)
Camera Dimension ⌀46*80mm ⌀40*100mm
Net Weight 0.3KG 0.7KG 0.3KG 0.7KG 0.5KG

Product information


1. Mini 46MM diameter network camera, suitable for ROV camera, diver helmet camera, pipeline camera, etc.

2. Built-in 128GB storage

3. Corrosion-resistant stainless steel, used in seawater for a long time.

 🎥Barlus underwater cameras are widely used in aquaculture cameras (fish farming, sea cucumber farming, etc.) , aquarium monitoring camera, shipboard camera, ship engine monitoring camera, marine pasture camera, underwater engineering acceptance camera, marine life detection camera, liquid operation camera for machine processing industry, etc.

Specific information

Focus Length: 2M(Support customization)

Supporting device: Support iOS, Android,Computer,NVR.

Supporting agreement: ONVIF, HTTP,DDNS, FTP,RTSP,RTMP,IPv4/IPv6,802.1x,HTTPS, TCP/IP, UDP, RTP, RTCP, UPNP,SMTP, NTP, DHCP, DNS, PPPOE, ;SDK Secondary development

Storage: Built-in 128GB TF card(Optional)

Waterproof: IP68(permanent installed underwater)

Cable: Industrial PU,diameter 7MM.Resistance 60KG pull ,anti-aging,anti-friction,resistance to seawater,special underwater material.

Use environment: Under Seawater and Fresh water

Working humidity: 0%-100%

Working Temperature: -20°~55°

Power Supply: DC12V-D36V

Packing: 1* Camera+1*U disk(software and mannual)

1 Year Warranty

Please use your Barlus underwater camera with peace of mind. We offer a one year warranty. If there is a quality problem with the camera it can be repaired or returned to you free of charge. Calculated from the date of receipt of the original order.

Learn more


Please do note that shipping is insured and takes 6-10 business days worldwide. However, you may receive your items earlier. Tracking Numbers will ALWAYS be sent so you can track them every step of the way! Cool things are worth waiting for!

100% Risk-Free Purchase

If you bought it and felt that it has some problem, don't worry. Just shoot us a message at contact and we will make it right by offering you a replacement or refund. 100% Simple & Risk-Free process.

View full details

About us

Barlus is a manufacturer that has always been dedicated to creating professional and practical underwater surveillance cameras. Feel free to contact us for any further needs!

Get images easily

Video viewing on mobile devices is supported. Convenient and fast, master the underwater dynamics at any time

Built-in 128GB memory card

The camera is equipped with a 128G capacity front-end storage card inside, which can be stored centrally in case of network failure and effectively avoid image loss in case of accident.

Share the wonderful underwater

1080P HD lens capture a clear picture for you. You can view the live video in the water remotely at any time. It can also be shared live to your social media platforms. Share this exciting moment in the water with your audience.

Mini body is compact and convenient

Only 46mm diameter underwater camera! Its compact size and ultra-light weight is very convenient to use underwater. It can support installation and fixed use on underwater robots, and also allows divers to use it head-mounted. It is completely weightless.

  • Underwater viewing

  • Aquaculture

  • Underwater Engineering Monitoring

1 of 3

Customer Reviews

Based on 1 review
Great quality and tech support

We are very pleased with the camera we purchased. Once installed, it is easy to connect to via smart device so you can watch and share camera live stream anywhere. Installation software and instructions are very technical, however, but the tech support was very responsive and timely and got us hooked up right away.
