Barlus

Cost-effective seawater network camera

Cost-effective seawater network camera

Regular price $430.00 USD
Regular price $650.00 USD Sale price $430.00 USD
Sale Sold out
Shipping calculated at checkout.
Model
Cable length
Power supply

For bulk purchases, please contact Tim (sales2@barluscam.com) or click on Chat with us below right to get a discount.🤑

Click below to view parameters👇

Model comparison

Model E3G2MPKX10
Lens 2.0mm (H.FOV:100° )
pixel 2 MP 1920×1080P 50FPS 1 MP 1280×720P  50FPS 1/2.8" SONY CMOS sensor, color 0.001Lux  F1.2,black/white 0.001Lux F1.2
Remote viewing of devices Only mobile phones
Fill light timing function Yessoftware control

Product information

🎥Barlus underwater cameras are widely used in aquaculture cameras (fish farming, sea cucumber farming, etc.) , aquarium monitoring camera, shipboard camera, ship engine monitoring camera, marine pasture camera, underwater engineering acceptance camera, marine life detection camera, liquid operation camera for machine processing industry, etc.

Supplementary light(mobile/PC /NVR Settings) :(Automatic light sensor control/manual control/time control) 3 modes ----3PCS white light, level 10 brightness, 1000 lumens
4PCS infrared lamps, grade 10 brightness, 1000 lumens

Color: Two modes:

1: white light - full color; 2: infrared light - automatic color for black;

Support equipment: Computer,NVR. Mobile (Android, iSO)

Support agreement: ONVIF, RTSP, RTMP,HTTP,DDNS, FTP,RTSP,IPv4/IPv6,802.1x,HTTPS, TCP/IP, UDP, RTP, UPNP,SMTP, NTP, DHCP, DNS, PPPOE, ;SDK Secondary development,

Texture: Seawater Grade Stainless Steel

Waterproof: IP68(Permanently installed underwater)

Pressure: Maximum 500Kpa (maximum water depth 50M)

Cable: Default length of 10 meters (Max. 80 meters),PU material, diameter of 7MM. 60KG .tension resistance, aging resistance, friction resistance, seawater corrosion resistance, special underwater wire.

Service environment:Land/vehicle-borne/shipborne/surface/Underwater (fresh and sea water)

Operating humidity: 0%-100%

Operating temperature: -20°~55°

Support the voltage:DC12V, When cable > 20m, DC24V power supply

Camera size: ⌀70*65mm

Weight: 1.2KG

Packaging:1 * camera ,1 * camera stand fittings ,1 * U disk (software and manual)

1 Year Warranty

Please use your Barlus underwater camera with peace of mind. We offer a one year warranty. If there is a quality problem with the camera it can be repaired or returned to you free of charge. Calculated from the date of receipt of the original order.

Learn more

Shipping

Please do note that shipping is insured and takes 6-10 business days worldwide. However, you may receive your items earlier. Tracking Numbers will ALWAYS be sent so you can track them every step of the way! Cool things are worth waiting for!

100% Risk-Free Purchase

If you bought it and felt that it has some problem, don't worry. Just shoot us a message at contact zhangli@barluscam.com and we will make it right by offering you a replacement or refund. 100% Simple & Risk-Free process.


Guarantee safe transportation& secure checkout

model E3G2MPKX10
lens 2.0mm (H.FOV:110° )
Resolution 2MP 1920×1080P 50FPS
1/2.8 Progressive Scan CMOS ,color 0.01Lux F1.2,black/white 0.001Lux F1.2
Fill light Infrared + white light. 1000 lumens brightness, ten levels adjustable.
Manual/Auto/Timer mode
supporting device Support iOS, Android, computer, NVR.
supporting agreement IPv4/IPv6,802.1x,HTTPS, HTTP, TCP/IP, UDP, RTP, RTCP, UPNP, RTSP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP,RTSP,ONVIF;SDK Secondary development
Material stainless steel
Waterproof level IP68 (permanently installed underwater)
Water pressure resistance Maximum 500Kpa (maximum water depth 100M)
cable The default length is 10 meters.
Working humidity 0%-100%
working temperature (-20°~55°
Power Supply Cameras with ≤20m cable are DC12V powered. Cameras with >20m of cable are powered by DC24V.
Camera size ⌀70*65mm
Weight Camera: 1.6KG (excluding cable), cable: 0.6KG, whole box: 2.75KG
Package 1 * Camera
1 * Camera bracket accessories
1 * U disk (software and manual)
View full details

About us

Barlus is a manufacturer that has always been dedicated to creating professional and practical underwater surveillance cameras. Feel free to contact us for any further needs!

Powerful body

The camera casing and cables are made of special underwater materials. Both sea and fresh water work
💪 Anti-corrosion
💪Anti-aging
💪 Anti-friction
💪 Resist 500KPa water pressure( Can be customized if you need longer cable and water pressure)
💪 Can work permanently underwater

Smart lighting

4pcs Infrared + 3 White LED Lights Camera,Infrared white light integrated system, support 10 levels light brightness adjustment for your freely choice of of light intensity as needed, making more convenience when you fishing.And you can switch the lights when you like.

HD Pixel

2MP/5MP UNDERWATER PHOTOGRAPHY - Combined with CMOS sensor 2.0mm lens, can capture footage at HD resolution for video .you can enjoy the real-time video from mysterious underwater world.

Multipurpose

Can be widely used in a variety of underwater scenes. Real-time broadcast of underwater moments for you.

  • Underwater viewing

  • Aquaculture

  • Underwater Engineering Monitoring

1 of 3

Customer Reviews

Based on 2 reviews
100%
(2)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
G
George
Excellent underwater ocean dock camera

"BOTTOM LINE: Excellent, high-quality camera that we can strongly recommend.

We own a small dive resort on the island of Utila in the Caribbean. We investigated underwater cameras for more than a year to install at the end of our 175ft dock shown in the 1st picture. The initial options we found were really expensive (thousands of dollars). We then researched cheaper options, but the other Chinese cameras we tried were of lower quality. Finally we found Barlus. We tried the 304L model but ultimately settled on the 316L. We now have 4 of them and plan to buy more. The bottom line is this a GREAT CAMERA from the price, and we have loved what we have seen on it around our dock (see photos attached). The top 5 reasons we like this camera:
(1) Solid, high quality stainless material and construction - it does not feel flimsy like some of the other cameras we tried. It has a sturdy stainless steel mounting bracket and the actual camera shell is heavy and feels really solid/durable. For us the is critical as it is mounted at the front of a dock, 10 ft under water, in an ocean that can be calm as a lake but can also have 3-4 ft waves crashing into and over the dock.
(2) Good to excellent support - when we had some questions on configuring the camera we got quick responses, and when we had a deeper technical question about the wiring inside the POE Splitter Box, we got an answer within one day, with a technical drawing answering our question. The same was true when we asked a sales related question. Our experience with other manufacturers varied a lot.
(3) Reasonable price - We bought the 316L camera. It was cheaper than other options but the quality was (much) better.
(4) The camera has super wide angle 2mm lens which is perfect for our use where we want to have a wide view of the underwater landscape. The image quality is reasonable/good (not great). But at full 1080P, 25 fps and the highest encoding settings it keeps up well. It works reasonably well in low light conditions, and also has infrared and LED lights that you can toggle from software (we don't use them often as we have underwater lights). Also easy to access the video stream with RTSP
(5) It can be powered by POE (over the ethernet wire) - this is essential for us as it allows us to power it over the same wire carrying the data from a Ubiquity switch almost 300 ft away from the camera.

There are some things we are not so crazy about / that could be better

(1) The software/firmware on the camera is not great (You need Windows and IE with ActiveX to log into the camera and configure it). Nor is the informal manual that comes with it. But is still better than any of the other cameras we tried. You can configure a ton of stuff on the camera including flipping/rotating the image, various encoding options, text/title overlays etc. but it feels like software from the early 2000's
(2) The Auto White Balance/Image quality could be better, but having said that the ocean is a tricky to handle, especially in lowlight situations
(3) We liked the short/stockier frame of the 304L camera and it mounting bracket. the 316L has a longer mounting bracket and lens tube. They are VERY solid, but for us they present a larger surface area for the ocean to pummel, and when it is very rough you get some camera movement with the 316L that you don't get with the 304L stockier frame
(4) We wish the camera could automatically check if it has the latest firmware, and give you the option to then download and install it (like all modern devices). On this one you must find the firmware on the internet and then manually install it.

P.s the photos are screenshots from the video feed and not snapshots saved from the camera directly."

K
K.R.
Best Underwater IP POE camera I have found!

I have purchased numerous underwater IP cameras for my pond and this is the firsat one that I’m happy with. This isn’t a security camera that can get wet, it’s truly designed for underwater use. Actually I have be so happy with the camera and support that I’ve purchased 3 more for myself and 3 for friends. I use the app on my phone and iPad. I use their VMS software on my Mac and their CMS software on PC both locally and remotely. I have also used the IE browser on the PC to view the cameras. The IR lights are pretty cool at night but but they don’t penetrate the water very far. The cameras are connected using POE on my network and I just purchase a Barlus NVR that I’m looking forward to hooking up so I may view on my TV via hdmi
