Pressure-resistant 3000m underwater ip camera for deep sea operation

$2,000.00 USD
$2,000.00 USD
Tax included. Shipping calculated at checkout.
Pixel: 4MP
Frame rate: 90FPS
Lens Type: Fixed-focus lens
Model: SW-SK4-4D9WJ-WV3000
  • PayPal

For bulk purchases contact Tim for discounts:sales2@barluscam.com
$2,000.00 USD
$2,000.00 USD


Model SW-SK4F-4D9WJ-WV3000 SW-SK5F-D5WJ-WV3000 SW-SK8F-4DWJ-WV3000
Lens Motorized focus 3.6mm (H.FOV:80°) lens
Fixed Focus 2.8mm (H.FOV:100°) lens
Pixel 4MP 2560×1440P 90FPS 5MP 2592×1944P 50FPS 8MP 3840×2160P 30fps
sensor 1/1.8" SONY CMOS sensor ,color 0.001Lux F1.2,black/white 0.0001Lux F1.2 1/2.8" SONY CMOS sensor ,color 0.001Lux F1.2,black/white 0.0001Lux F1.2 1/1.8" SONY CMOS sensor ,color 0.001Lux F1.2,black/white 0.0001Lux F1.2
Fill light None
Image color Color
Support Devices Computer, NVR.
Support Protocols IPv4/IPv6,802.1x,RTSP,RTMP,ONVIF;HTTP,HTTPS,  TCP/IP, UDP, RTP, RTCP, UPNP, RTSP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP,SDK Secondary development
Texture Seawater grade stainless steel
Waterproofing grade IP68(Permanently installed underwater)
Pipeline pressure test Maximum 30MPa (maximum water depth 3000M)
connector 8-pin watertight connector
Service environment Land/vehicle/ship/surface/underwater
Operating temperature -20°~55°
Power Default DC24V
Camera Size ⌀70*140mm
Camera weight 1.5KG

Barlus

Compatible with Deep Sea Tools

Underwater vehicles, remotely operated vehicles (ROVs), or autonomous underwater vehicles (AUVs) designed for exploring the deep sea. A 3000-meter resistance ensures functionality at considerable depths.Underwater equipment used in the oil and gas industry, such as remotely operated vehicles for underwater inspections of subsea infrastructure

True deep-sea underwater IP cameras

A true underwater camera for the deep sea. After many water pressure tests. Resistant to the strong pressure from the deep sea.
Resistant to seawater corrosion👍
Can be installed underwater all the time👍
Permanently waterproof👍

Lens and pixel selectable

1. Fixed focal length lens and adjustable focal length lens are optional. Get unrivaled image quality or versatile framing.
2. 2MP/5MP/8MP can be selected. Strike a balance between resolution and storage efficiency.

Visualizing the deep sea

Cameras resistant to seawater corrosion and capable of withstanding extreme water pressures play a vital role in various fields, enabling exploration, research, industry, and visual documentation of the deep-sea environment. Their robust design ensures functionality and reliability in the challenging conditions of the ocean depths.
